smart li-ion 3.7 volt battery 3000mah rechargeable for heated clothing
the 3.7 volt battery can be charged for over 500 times with 4.2v 1.2A output matching charger( two-pin,one or two output cable) .
You can buy the whole battery kit, or buy the battery , the charger separately.
Specification of the 3.7 volt battery
Brand | KXD |
Model | KXD-37300L3.0Ah-VP |
Nominal Voltage | 3.7V |
Nominal Capacity | 3000mAh |
Standby Current | ≤15μA |
Working Efficiency | ≥99% |
Operating Voltage Range | 4.2V-3.0V |
Max. Output Power | 10W |
Load Resistance | 5Ω-200Ω |
Charge Cut-off Voltage | 4.2V |
Discharge Cut-off Voltage | 3.0V |
Cycle Life | above 500 cycles |
Internal Resistance (Max, at 1000Hz.): | ≤230 mΩ |
Battery Dimention(MM) | 15mm(T)*48mm(W)*65mm(H) |
Output/Input Port | DC/1.35*35/7.0mm |
Battery Weight | 70g |
Charge Temperature | 0°C~45°C;32°F~113°F |
Discharge Temperature | -20°C~60°C; -4°F~149°F |
Storage Temperature | -20°C~45°C;-4°F~113°F |
Battery color | milky |
Storage Performance | 75% power remains for one year |
Specification of matching charger
Input Voltage Range | AC100V~240V 50/60Hz |
Charge Mode | CC/CV |
Plug | American plug or customized |
Output Voltage | 4.2V |
Output Current | 1200mA |
USB | dual USB DC:1.35*3.5/7mm |
Weight | 80g |
Charge Time | 3-4hours |
Led Indicator | with turnlight,the color will turn red to green when it's fully charged. |
Features
1. LED Indicator:
Long press the switch for 3 seconds,you can see the led disply or percentage on the side face ,diferent color and percentage refers to different battery level:
LED Battery Indicator | red 85% |
orange 50% | |
green 25% | |
on-off key(long press for 3 seconds) |
2. Three-step Temperature Regulator:
Connected to the load ,the battery will enter into working stage.
You can press the swich to adjust the output power,in this way ,you can adjust the heating temperature of the heating element in the gloves,insoles,shoes,or kneepads.
We recommend to use 1.5w-2.0w heating element with KXD smart li-ion battery pack 3.7v.
output power regulation(contect the battery to the load,long press the button for 3 seconds) | red 99% |
orange 60% | |
green 30% | |
on/off |
3. Pulse Output:
3.7V pulse output,"1-on-1-off"working mode,convert from on to off freely,it can save more energy than DC output battery,while don't effect heating of your gloves,insoles,shoes,etc.
4.Easy to operate
fast to charge(3-4 hours)
low voltage---no harm to human being and pets
waterproof-maintenance free
portable-easy to carry
Applications of the 3.7 volt battery:
lithium polymer rechargeable battery packs KXD-37300L3.0Ah-VP is mainly used for following products,
About Us
KXD is a professional battery manufacturer ,our products include lithium-ion battery, 18650 lithium batteries, lithium polymer batteries, LiFePO4 batteries, lithium battery packs, chargers ,heated clothing batteries,etc.
Our products are of high performance ,low self discharge,long cycle life ,good duration of use at both high temperature and low temperature,which are mainly and widely used for Aviation Supplies,Mobile Devices,EV and E-bike,Medical Equipments,Small-size Household .Appliances,etc.
Equiped with ISO9000, QS9000, ISO14000 and OHSA18001 management system certification, all our product are UL , TUV, ROHS,CE,UN38.3 approved.Our sales network expanded to corners all over the world in past years .
